Name: 200km-class Tactical Datalink S920
Brand: GT Advanced Defense & Tactical Solutions
Availability: InStock
Rating: 5 (1 reviews)

Description

Key Features

Feature	Description
Long-Range Transmission	Up to 200 km (LOS) for extended UAV missions
Adaptive Frequency Hopping	Dynamic spectrum adjustment for stable links in interference environments
Intelligent Spectrum Sensing	Real-time RF monitoring and automatic frequency selection
Secure Communication	AES256 encryption for protected data transmission
Low Latency	<30 ms propagation delay for real-time control and video
High Throughput	Up to 20 Mbps for video + telemetry + command
Flexible Interfaces	Supports RJ45, RS232, TTL/SBUS (expandable to RS422/RS485)
Compact Design	Lightweight form factor for easy UAV integration

Technical Specifications

Parameter	Specification
Model	S920
Transmission Distance	Up to 200 km (LOS)
Frequency Band	Default 1.4 GHz (customizable 0.7–2.7 GHz)
Transmission Power	0–40 dBm
Throughput	Up to 20 Mbps
Channel Bandwidth	1.25 / 2.5 / 5 / 10 MHz
Latency	< 30 ms
Interfaces	RJ45 ×2, RS232 ×2, TTL/SBUS ×1
Operating Temperature	−40°C to +65°C
Storage Temperature	−40°C to +85°C
Weight	~600 g
Dimensions	209.9 × 113 × 28 mm

Typical Applications

Key Differences (At-a-Glance)

200km-class Tactical Datalink S920
