Name: 50km-class Tactical Datalink S905
Brand: GT Advanced Defense & Tactical Solutions
Availability: InStock
Rating: 5 (1 reviews)

50km-class Tactical Datalink S905

50km-class point-to-point UAV datalink designed for small platforms, delivering stable video, telemetry and control links with adaptive frequency management in complex RF environments.

Long-range point-to-point UAV datalink for small UAV missions
Adaptive frequency selection and hopping for interference resilience
Low-latency transmission of video, telemetry and control data

Best for small UAV platforms under 50km missions.
For longer range point-to-point, consider S910 / S920 / S930.

Description

Key Features

Feature	Description
Transmission Range	Up to 50 km (LOS)
Adaptive Spectrum Management	Intelligent frequency selection based on RF environment
Anti-Interference	Real-time interference detection and avoidance
Encryption	AES256 secure air interface transmission
Latency	< 30 ms propagation delay
Form Factor	Compact and lightweight for small UAV integration
Architecture	SDR-based, flexible and upgradable

Technical Specifications

Parameter	Specification
Model	S905
Transmission Distance	Up to 50 km (LOS)
Frequency Range	1.4 GHz (0.7–2.7 GHz customizable)
Output Power	0–31 dBm
Throughput	Up to 20 Mbps
Latency	< 30 ms
Bandwidth Options	1.25 / 2.5 / 5 / 10 MHz
Weight	~260 g
Dimensions	129.1 × 83.2 × 21.6 mm
Operating Temperature	−40°C to +65°C

Typical Applications

Small UAV reconnaissance and surveillance
Border and perimeter patrol
Emergency response and disaster monitoring
Mobile security and inspection missions

Key Differences (At-a-Glance)

Category	S905	S910	S920	S930	S950
Size / Weight	★★★★★ (Ultra-compact)	★★★★☆	★★★☆☆	★★☆☆☆	★☆☆☆☆
Range Capability	★★☆☆☆	★★★☆☆	★★★★☆	★★★★★	★★★★★+
Throughput	★★☆☆☆	★★★☆☆	★★★★☆	★★★★☆	★★★★★
Anti-Interference	★★★☆☆	★★★★☆	★★★★☆	★★★★★	★★★★★+
Link Robustness	★★☆☆☆	★★★☆☆	★★★★☆	★★★★★	★★★★★+
Typical Platform	Micro UAV / UGV	Small UAV	Medium UAV	Large UAV	Heavy-duty UAV

50km-class Tactical Datalink S905

Description

Contact Our Engineers, Discuss Your Mission Requirements.
