Key Features
| No. | Product | Features |
| 1 | CRPA Antenna Quantity | Larger 4-Element CRPA Antenna – A physically larger antenna aperture improves signal capture, reception gain, and anti-interference spatial nulling performance |
| 2 | Dual-Frequency GNSS Support | Supports GPS L1 and BDS B1I for resilient navigation continuity |
| 3 | Anti-Jamming Immunity Direction | Up to 4 simultaneous jammer suppression |
| 4 | Anti- spoofing | Powerful Anti-Spoofing Beyond Standard 4-Element Solutions – Suppresses asynchronous, synchronous, and relay spoofing while outputting clean GNSS signals to the backend receiver. |
| 5 | Anti-jamming | 105 dB Anti-Jamming Performance – Delivers excellent protection against narrowband, broadband, pulse, sweep, and Gaussian interference |
| 6 | Multi-Platform Deployment | Ideal not only for UAVs, but also unmanned ground vehicles (UGVs), autonomous robots, unmanned vessels, and intelligent mobile systems |
| 7 | Easy Integration | Compatible with PX4, Ardupilot, Pixhawk, CUAV V5+, and other mainstream flight control ecosystems |
| 8 | Data Output | NMEA 0183 / ublox protocol output (PVT output can be customized) |
| 9 | Port Type | TTL (or RS422) and RF dual integration modes |
| 10 | Power Supply | 5–17 VDC (12 V recommended) |
Technical Specifications
See specification table below:
| NO. | Parameter | Specification |
| 1 | Frequency | BDS B1 / GPS L1 |
| 2 | Anti-jamming | 105 dB ISR (single source) |
| 3 | Multi-jammer | Up to 3 jammers |
| 4 | Position Accuracy | ≤10 m under jamming |
| 5 | Velocity Accuracy | ≤0.2 m/s |
| 6 | Timing Accuracy | ≤100 ns |
| 7 | Power Input | 5–17 VDC (12 V recommended) |
| 8 | Power Consumption | ≤13 W |
| 9 | Dimensions | 150 × 130 × 22 mm |
| 10 | Weight | ≤550 g |
Typical Applications
Ideal for UAV navigation protection, autonomous platform guidance, fleet defense, critical infrastructure timing, and secure logistics navigation. For autonomous systems operating in spoofing-heavy or GNSS-denied environments, AJT105S delivers a decisive advantage over traditional 4-element terminals through stronger anti-spoofing intelligence, better reception performance, and true multi-domain platform adaptability.
It is similar to the 8/16/32 Element CRPA anti-jamming terminal, AJT105S fully compatible with mainstream open-source flight controllers including PX4, Ardupilot, Pixhawk, and V5+ platforms, enabling rapid integration without modifying navigation algorithms.
